Double ultrasonic cleaning tank / double flushing tank / single drying tank. This design is used to clean seriously polluted parts. Contaminants, but some may still require zero residue cleaning results.

單超聲波清洗槽/三/單干燥。本系統是專為輕臟的零件設計的，并要求絕對零殘留清洗結果.

Single ultrasonic cleaning tank / three / single drying. This system is specially designed for light dirty parts and requires absolute zero residue cleaning results

單超聲波清洗槽/單水龍頭沖洗槽/雙沖洗槽/單干槽。此設計適合于零件。要求對典型污染物進行零殘留清洗，當包括閉環去離子系統。自來水沖洗超聲波清洗機大大降低了對直接輸入系統的維護要求。

Single ultrasonic cleaning tank / single faucet flushing tank / double flushing tank / single dry tank. This design is suitable for parts. Zero residue cleaning of typical pollutants is required, when including closed-loop deionization system. The tap water washing ultrasonic cleaning machine greatly reduces the maintenance requirements of the direct input system.

這個系統也可以定制制造適合任何5槽。處理要求

This system can also be customized to fit any 5 slots. Processing requirements

可將超聲添加到任何液體軸承箱中.

Ultrasonic fluid can be added to any bearing housing

在與所有潔升超聲波清洗機一樣，是使用高等級的材料可用，并包括諸如顆粒等特性過濾，不銹鋼訪問板，和數字循環計時器增加清潔劑和系統的使用壽命，同時提供操作方便。控制裝置是用玻璃纖維封裝的。電氣外殼而不是鋼外殼消除可能腐蝕。系統還包括帶球閥的排泄口和填充口。提供容易的液體維護操作。

Like all Jiesheng ultrasonic cleaning machines, it uses high-grade materials available, and includes characteristic filtration such as particles, stainless steel access board, and digital circulation timer to increase the service life of detergent and system, while providing easy operation. The control device is encapsulated in glass fiber. Electrical enclosures instead of steel enclosures eliminate possible corrosion. The system also includes drain and fill ports with ball valves. Provide easy liquid maintenance operation.

超聲波清洗是在第一個不銹鋼槽和第二。槽體采用雙超聲波清洗槽。超聲選擇包括操作頻率的選擇，或我們的交叉火力多頻超聲為大多數應用程序提供佳清潔效果的系統。在超聲波清洗槽用高效率的數字加熱器加熱溫度控制器，連續顯示浴溫。a.a微粒過濾系統也包括去除微粒和清洗槽中的污染物，從而增加其預期壽命。過濾器 外殼安裝在方便的位置，以供維修。在數字超聲定時器自動檢測超聲波清洗循環完成時。

Ultrasonic cleaning is in the first stainless steel tank and the second. The tank body adopts double ultrasonic cleaning tank. Ultrasound selection includes the choice of operating frequency, or our cross fire multifrequency ultrasound system that provides good cleaning for most applications. In the ultrasonic cleaning tank, a high-efficiency digital heater is used to heat the temperature controller and continuously display the bath temperature. a. A the particulate filtration system also includes the removal of particles and contaminants in the cleaning tank, thereby increasing its life expectancy. The filter housing is installed in a convenient location for maintenance. When the digital ultrasonic timer automatically detects the completion of the ultrasonic cleaning cycle.

浸沒式?jīng)_洗是用2或3個裝有反向級聯溢出。在此配置中，沖洗槽設計為反向級聯溢出格式，其中兩個沖洗槽共享同樣的供水，大大減少了水的消耗。a2“溢流堰包括在主Rinse中，以確保溢流。液體均勻地從油箱中拉出來。

Immersion flushing is carried out with 2 or 3 spills equipped with reverse cascade. In this configuration, the flushing tank is designed as a reverse cascade overflow format, in which two flushing tanks share the same water supply, greatly reducing water consumption. The A2 "overflow weir is included in the main rinse to ensure that the liquid is pulled evenly out of the tank.

處理槽包括一個高容量部分循環干燥系統，包括電加熱器芯和4“門控式濕空氣排氣系統干燥環境。氣流以部分為導向，以大限度地干燥。速度。不銹鋼蓋包括保持干燥環境封閉。干燥系統的設計是以空氣體積而不是過高的溫度來干燥零件，因此，允許操作員更快地處理籃子完成干燥循環。空氣管道是專門為消除液體進入干燥系統的可能性。

The treatment tank includes a high-capacity partial circulation drying system, Including electric heater core and 4 "The door controlled wet air exhaust system is designed to dry the environment. The air flow is partially oriented to maximize the drying speed. The stainless steel cover includes keeping the drying environment closed. The design of the drying system is to dry the parts with the air volume rather than too high temperature, so it allows the operator to handle the basket faster to complete the drying cycle. The air duct is designed to eliminate the entry of liquid into the drying The possibility of the system.
