Micro is small, and nano is small to nano level. Applications: CPU, mobile phone CPU, various microelectronic chips (bank card, bus card, mobile phone SIM card, sound processing chip in headset, etc., as well as U disk and other semiconductor storage devices based on silicon materials). The production materials are mainly silicon. Silicon material resources are relatively rich, and the preparation process is mature; Other application directions are also useful for compound semiconductors.

微納器件一般以微納光學元件為主，基本上以納米為計算單位的器件都可稱為微納器件。

Micro nano devices are generally based on micro nano optical elements, and devices with nano as the calculation unit can be called micro nano devices.

對于此行業來說，清洗是少不了的一道工序。超聲波清洗機就是被廣泛運用到了各行各業起到了較好的清洗作用。

For this industry, cleaning is an indispensable process. Ultrasonic cleaning machine is widely used in all walks of life and plays a better cleaning role.

而被清洗的產品有大有小、量多量少、簡單復雜。其中就需先了解下尺寸大小，對于微納的清洗也是一樣的。超聲波清洗機的內槽尺寸是L280×W390×H260(mm)，材質選用的是進口SUS316板，δ2.0mm。

The cleaned products are large and small, large and small, simple and complex. Among them, it is necessary to understand the size first, and the cleaning of micro nano is the same. The inner groove size of the ultrasonic cleaning machine is l280 × W390 × H260 (mm), made of imported SUS316 board, δ 2.0mm。

此臺超聲波清洗機的槽體每槽設四面溢流口，溢水槽寬35mm，各槽皆為獨立循環槽，由循環泵將洗劑由儲液箱抽出經過濾后再運回清洗槽，即子母槽循環。

Each tank of this ultrasonic cleaning machine is equipped with four overflow ports. The overflow tank is 35mm wide. Each tank is an independent circulating tank. The detergent is pumped out of the liquid storage tank by the circulating pump, filtered and then transported back to the cleaning tank, that is, the child and mother tank are recycled.

儲液箱結構的優勢則是由隔板分成兩腔，分油后的清潔溶液經循環泵重新抽入清洗槽，實現自我循環，提高溶液的利用率，而分離后的油排放到總排管。

The advantage of the liquid storage tank structure is that the diaphragm is divided into two chambers, and the cleaning solution after oil separation is pumped into the cleaning tank again through the circulating pump to realize self circulation and improve the utilization rate of the solution, while the separated oil is discharged to the main discharge pipe.

VGT-1509FH超聲波清洗機的優勢還是顯而易見的：

The advantages of vgt-1509fh ultrasonic cleaner are obvious:

1、槽面設齒狀溢流結構，純水由純水預熱箱進入。槽外貼保溫棉厚10mm。

1. The groove surface is provided with a toothed overflow structure, and the pure water enters from the pure water preheating box. 10mm thick insulation cotton is pasted outside the groove.

2、槽體上部設抽風小孔，將溢出水蒸汽抽走，防止水汽再次附著于提出的產品上。

2. The upper part of the tank is provided with an air extraction hole to remove the overflow steam and prevent the steam from adhering to the raised product again.

3、在烘干槽頂部加設FFU系統，有效減少環境對洗凈效果的影響。（工件加溫后，對灰塵的附著力增強，F(xiàn)FU形成負壓可有效減少環境對洗凈效果的影響，從而從根本上提高產品合格率）。

3. An FFU system is added at the top of the drying tank to effectively reduce the impact of the environment on the cleaning effect. (after the workpiece is heated, the adhesion to dust is enhanced, and the negative pressure formed by FFU can effectively reduce the impact of the environment on the cleaning effect, so as to fundamentally improve the product qualification rate).

4、每個烘干槽配置一套氣缸，氣缸帶動產品一起運動，形成密封蓋。

4. Each drying tank is equipped with a set of air cylinders, which drive the products to move together to form a sealing cover.

5、籃子的下面放置一支撐結構，以方便風源更加通透作用于工件。

5. A supporting structure is placed under the basket to facilitate the air source to act on the workpiece more thoroughly.

6、在烘干槽正上方的機架頂部設置一個FFU層流送風單元。由上往下吹風形成負壓風，致使工件加熱后附著物不易粘附。

6. An FFU laminar air supply unit is set on the top of the rack directly above the drying tank. The negative pressure wind is formed by blowing from top to bottom, which makes the attachment difficult to adhere after the workpiece is heated.

7、拋動機構：清洗過程中工件作均勻地拋動，可以增加工件與液體的摩擦，有利于表面污垢迅速脫落，提高清洗效果。

7. Throwing mechanism: the workpiece is evenly thrown during the cleaning process, which can increase the friction between the workpiece and the liquid, which is conducive to the rapid fall off of surface dirt and improve the cleaning effect.

以上就是為大家介紹的有關超聲波清洗設備的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://www.jzjuhe.com

The above is a detailed introduction about ultrasonic cleaning equipment for you. I hope it can help you. If you have any questions, please contact us. We will provide services for you with a professional attitude http://www.jzjuhe.com
