The fully automatic high-pressure water deburring and cleaning machine utilizes the principle of high-pressure water jet to deburr, clean, and remove sand from precision parts and products. Effectively remove burrs, chips, and oil impurities from cross holes, inclined holes, threaded holes, and blind holes inside the parts. It is suitable for deburring and cleaning various nodular cast iron, gray iron, powder metallurgy, cast aluminum alloy, zinc alloy, stainless steel parts, such as automobile engine, gearbox, refrigeration compressor, ship, aircraft engine, products, molds, etc.

自動高壓水毛刺清洗機是利用高玉水射流原理對精密零件產品進行去毛刺、清洗及除砂。有效去除零件內部的交叉孔、斜孔、螺紋孔以及盲孔的毛刺、切屑及油污雜質。適用于汽車發動機、變速箱、制冷壓縮機、船舶、飛機發動機、 產品、模具等各種球墨鑄鐵、灰口鑄鐵、粉末冶金、鑄造鋁合金、合金、不銹鋼零件的去毛刺清洗。

The automatic high-pressure water burr cleaning machine utilizes the principle of high jade water jet to deburr, clean, and remove sand from precision parts and products. Effectively remove burrs, chips, and oil impurities from cross holes, inclined holes, threaded holes, and blind holes inside the parts. It is suitable for deburring and cleaning various nodular cast iron, gray iron, powder metallurgy, cast aluminum alloy, alloy, stainless steel parts, such as automobile engine, gearbox, refrigeration compressor, ship, aircraft engine, products, molds, etc.

全自動高壓水去毛刺機通過恰當?shù)倪x配壓力、流量及進給速度,可獲得與毛刺特性相適應的佳去毛刺參數。同時配以自動清洗系統、零件吹干系統,減輕加工人員的勞動強度,增加生產中的現代化水平。此套系統加工效率高、清洗干凈、可靠性高、操作簡便,高效環保,節約用水,能有效節約生產過程中日常成本投入。

The fully automatic high-pressure water deburring machine can obtain optimal deburring parameters that are suitable for deburring characteristics through appropriate selection of pressure, flow rate, and feed speed. Equipped with automatic cleaning system and part drying system, it reduces the labor intensity of processing personnel and increases the modernization level of production. This system has high processing efficiency, clean cleaning, high reliability, simple operation, high efficiency, environmental protection, water conservation, and can effectively save daily cost investment in the production process.

全自動高壓水去毛刺清洗機是典型的機電一體化裝置,它綜合運用了機械與精密機械、微電子與計算機、自動控制與驅動、傳感器與信息處理以及人工智能等多學科的新研究成果,隨著經濟的發展和各行各業對自動化程度要求的提高,自動去毛刺機技術得到了迅速發展,出現了各種各樣的去毛刺機產品。自動去毛刺機產品的實用化,既解決了許多單靠人力難以解決的實際問題,又促進了工業自動化的進程。自動去毛刺機就是將機器視覺及數字圖像處理技術應用于自動

The fully automatic high-pressure water deburring cleaning machine is a typical mechatronics integration device, which comprehensively utilizes new research achievements from multiple disciplines such as machinery and precision machinery, microelectronics and computers, automatic control and driving, sensors and information processing, and artificial intelligence. With the development of the economy and the increasing requirements for automation in various industries, the technology of automatic deburring machines has rapidly developed, and various deburring machine products have emerged. The practicality of automatic deburring machine products not only solves many practical problems that are difficult to solve solely by manpower, but also promotes the process of industrial automation. Automatic deburring machine is the application of machine vision and digital image processing technology to automatic

化去毛刺系統中,采用機器視覺對孔位進行探測,并對攝像機內外參數標定的計算方法進行了詳細的論述,并根據標定進行物像變換,將目標點在攝像機坐標系下的坐標變換到去毛刺機器人坐標系中,從而獲取了空間目標點的三維空間坐標,然后再采用兩步法對去毛刺機器人進行導引|控制。

In the deburring system, machine vision is used to detect hole positions, and the calculation method for camera internal and external parameter calibration is discussed in detail. Based on the calibration, object image transformation is carried out, and the coordinates of the target point in the camera coordinate system are transformed into the deburring robot coordinate system, thus obtaining the three-dimensional spatial coordinates of the spatial target point. Then, a two-step method is used to guide and control the deburring robot.
