高壓噴淋清洗機是對工件通過清洗、漂洗、切水、烘干等工藝以達到工件表面無油污、鋁屑、水分的目的。本機需將清洗的工件放置在清洗機上料口專門設計的定位工裝上，通過高壓水噴淋清洗、漂洗達到工件表面清潔的效果，再通過壓縮空氣風切去除工件表面的大部分水分，然后進入熱風干燥工位，對工件進行烘干，處理工件表面殘留水分;經冷風冷卻后，回到上下料工位，人工將工件取出，完成整個清洗過程。清洗完成后，保證工件表面無污物及水珠。
High pressure spray cleaning machine is used to clean, rinse, cut water, and dry the workpiece to achieve the goal of no oil, aluminum chips, and moisture on the surface of the workpiece. The machine places the workpieces to be cleaned on the positioning tooling specially designed for the feeding port of the cleaning machine. The surface of the workpieces is cleaned by high-pressure water spraying and rinsing, and then most of the moisture on the surface of the workpieces is removed by compressed air cutting, and then enters the hot air drying station to dry the workpieces and deal with the residual moisture on the surface of the workpieces; After being cooled by cold air, return to the loading and unloading station and manually take out the workpiece to complete the whole cleaning process. After cleaning, ensure that the workpiece surface is free of dirt and water drops.
一、清洗特點
1、 Cleaning characteristics
清洗節拍快，效果統一，不會對工件造成磨損;設備中每個環節的工作時間、溫度和功率可以按需設置;設備上料采用雙確認按鈕，并配有安全光柵，確保操作人員安全;獨立控制柜，上下料工位處配有懸臂控制面板。
The cleaning rhythm is fast, the effect is uniform, and the workpiece will not be worn; The working time, temperature and power of each link in the equipment can be set as required; Double confirmation buttons are used for equipment loading, and safety gratings are provided to ensure the safety of operators; Independent control cabinet, equipped with cantilever control panel at the loading and unloading station.
二、設備組成
2、 Equipment composition
SUS304高級不銹鋼清洗儲液箱、 高壓水泵、化工泵、管道泵，均按照客戶需求量身定做。可連續長時間工作、內置式安全發熱系統、可調式溫度控制系統、安全及操作簡便、可按客戶要求設計及制造 。
SUS304 high-grade stainless steel cleaning reservoir, high-pressure water pump, chemical pump and pipeline pump are all customized according to customer needs. It can work continuously for a long time, built-in safe heating system, adjustable temperature control system, safe and easy to operate, and can be designed and manufactured according to customer requirements.

(1)可大批量連續自動作業。
(1) Large batch continuous automatic operation is available.
(2)適用于簡單結構及管件制品清洗。
(2) It is suitable for cleaning simple structures and pipe fittings.
(3)可采用鍍鋅及不銹鋼外殼，內部配噴淋管道，封閉經過式通道。整機為全封閉結構，采用不銹鋼或(方通)骨架焊接而成，清洗機上罩部分采用單層結構，采用不銹鋼鋼板制作，外貼有保溫層，降低能耗。
(3) Galvanized and stainless steel shells can be used, with spray pipes inside, and closed passage. The whole machine is a fully enclosed structure, which is welded with stainless steel or (Fangtong) skeleton. The upper cover of the cleaning machine is a single-layer structure, which is made of stainless steel plate, and is covered with a thermal insulation layer to reduce energy consumption.
儲液箱采用單層結構，采用SUS304不銹鋼板制作;內部用隔板分成幾個區域，分別實現對清洗液的過濾、鐵屑的沉淀、濾油、分油;儲液箱設有補水口、排液口、溢水口。底部為兩邊向中間傾斜，清洗液從液箱底部的排液口集中排出。
The liquid storage tank is of single-layer structure and made of SUS304 stainless steel plate; The inner part is divided into several areas with a partition board to filter the cleaning solution, precipitate iron filings, filter oil and separate oil; The liquid storage tank is provided with a water make-up port, a liquid discharge port and an overflow port. The bottom is inclined from both sides to the middle, and the cleaning solution is discharged from the drain port at the bottom of the tank.
液箱裝有液位控制器，液位異常時及時提醒補水、停水。異常情況實現緊急停機。
The liquid tank is equipped with a liquid level controller, which will timely remind to replenish and stop water when the liquid level is abnormal. Emergency shutdown shall be realized under abnormal conditions.
防銹箱內部裝有不銹鋼電加熱器，在30～60分鐘內將液體由室溫升至使用溫度。溫度自動控制在10～90℃范圍，人工設定、自動控制。設有溫控儀表自動顯示。液箱外貼保溫棉，防止熱量散發。
Stainless steel electric heater is installed inside the rust proof box to raise the liquid temperature from room temperature to service temperature within 30~60 minutes. The temperature is automatically controlled within the range of 10~90 ℃, manually set and automatically controlled. It is equipped with temperature control instrument for automatic display. The external surface of the tank is covered with insulating cotton to prevent heat emission.
三、清洗優勢
3、 Cleaning advantages
在所有的清洗方式中，噴淋清洗機是效率高、效果統一的一種方式，之所以噴淋清洗機能夠達到如此的效果，是與它獨特的工作原理和清洗方法密切相關的。我們知道，在生產和生活當中，需要清洗的工件種類和環節也很多，如：物件的清除油污、灰塵、表面防銹等，常見的手工清洗方法速度慢、成本高。而噴淋清洗機則可以對工件批量清洗，效果統一、可控性強，低成本，因此，噴淋清洗機被日益廣泛應用于各行各業。
In all cleaning methods, spray cleaning machine is a way with high efficiency and uniform effect. The reason why spray cleaning machine can achieve such effect is closely related to its unique working principle and cleaning method. We know that in production and life, there are many types and links of workpieces that need to be cleaned, such as removing oil stains, dust, surface rust prevention, etc. Common manual cleaning methods are slow and costly. The spray washer can clean the workpieces in batches with uniform effect, strong controllability and low cost. Therefore, the spray washer is increasingly widely used in all walks of life.
高壓噴淋清洗機具有功能全，結構合理，操作方便，清洗效果好,對于大批量工件的清洗，改善勞動環境，提高清洗質量，具有重要意義。
High pressure spray cleaning machine has full functions, reasonable structure, convenient operation and good cleaning effect. It is of great significance for cleaning large quantities of workpieces, improving the working environment and improving the cleaning quality.
